Specifications

Processor	Exynos 5410 Octa Core 1.7GHz ARM A15 or A7
OS	Android 4.2 Jelly Bean
Display	TFT LCD 10.1” HD (1280 x 800) or 10 Point Multi-touch Screen Panel
Memory (RAM)	DDR3 2GB DRAM
Storage (Flash)	eMMC 4.41 8 GB or microSD (max. 32 GB)
USB	USB 3.0 x 2Ch(Host/Device), USB 2.0 Device(OTG)
Camera	1Port ( USB Video Class Camera )
WIFI B/T	802.11 b/g/n or dual-band 2.4 GHz and 5Ghz
Network	10/100Beas-T, Link/ACT LED
Audio output	400mW stereo speakers, MIC IN, Headset
Gyroscope	Digital-output of 6 or 9-axis MotionFusion data
GPS	400mW stereo speakers, MIC IN, Headset
Composite video input	NTSC (N, 4.43), PAL (B, D, G, H, I,M, N) Video Data Supports ITU−R BT.601
HDMI	1.4a HDMI Standard 19Pins Connector (1080p)
Power supply	DC 12V/2A adapter, power consumption 5W and below

Applications

• Central control module of mobile devices
• Smart home system, DID, automotive multimedia device
• Industrial control/monitoring system
